pvc bending machine of window machine

pvc bending machine's Technical Parameter:Input Voltage/frequency380V/ 50 HzInput Power12.6 KWWorktable dimension2850mm×1250mm×800mmAir heating box Dimension3500mm×600mm×1003mmWeight900 KGStructure Feature of PVC bending machineThis bendingmachine is made up of bending and shaping worktable, air heating box, shaping belt, and filling belt. It features reliable function, safe operation, and high efficiency.Function Explanation of pvc bending machine After being filled up, profile and softened in the heating box, and then it can be bent and finalized to the design of semicircle you need whose diameter is between 500mm and 1800mm or arch of any type whose diameter is not more than 3000mm on the worktable. Further it can use different shaping belt according to different profile.Special HintWhen installing, you must do grounding it according to the electric wiring diagram. Keep the working floor clean, prevent from sliding and freezing. The degree of tightness should be suit as the profile is being filled up. The presetted temperature of the heating box and the heating interval of the profile need adjusted according to the current area air temperature and the profile. After finishing work, you must shut the electric power, clean the worktable surface and hood the plastic cloth as dustproof.
